WS-500 Model Gantry Shear with 5000kn Max Cutting Force and 1400mm Blade Length for Scrap Metal Processing

  • WS-500 Model Gantry Shear with 5000kn Max Cutting Force and 1400mm Blade Length for Scrap Metal Processing
  • WS-500 Model Gantry Shear with 5000kn Max Cutting Force and 1400mm Blade Length for Scrap Metal Processing
  • WS-500 Model Gantry Shear with 5000kn Max Cutting Force and 1400mm Blade Length for Scrap Metal Processing
  • WS-500 Model Gantry Shear with 5000kn Max Cutting Force and 1400mm Blade Length for Scrap Metal Processing
Certificação ISO
Quantidade de ordem mínima 1
Preço 52000

Contacte-me para amostras grátis e vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

Se você tem algum interesse, nós fornecemos a ajuda online de 24 horas.

x
Detalhes do produto
Modelo não. WS-500 Força de corte máximo 5000kN
Comprimento da lâmina 1400mm Taxa de produção 6-8t/h
Poder 90KW Força nominal de 400 toneladas
Tipo acionado Hidráulico Comprimento máximo 1600MM
Tensão 21.5mpa Nota automática Automático
Altura da tesoura 300/420 mm Capacidade de produção 5 conjuntos/mês
Cor Personalizado Tipo de controle CLP
Tipo de operação Apertar o botão
Destacar

WS-500 Model Gantry Shear

,

5000kn Max Cutting Force Scrap Metal Shear

,

1400mm Blade Length Horizontal Metal Shear
Deixe um recado
Descrição de produto
WS-500 Horizontal Scrap Non-Ferrous Metal Shear Machine
The WS Horizontal Metal Shear is designed for economical scrap processing with easy operation and flexible transportation via a roll on/roll off system. Various models are available to meet different production requirements.
Applications
Ideal for processing scrap metal, the HPM series of horizontal balers work with manual belting for efficient material handling.
Key Features
  • Horizontal structure allows for manual or automatic feeding with conveyor
  • PLC control and push-button operation ensure safe and reliable performance
  • High output capacity for efficient production
Specifications
Product Name:
WS Horizontal Metal Shear
Condition:
New
Application:
Scrap metal
Nominal Force:
400Ton
Driven Type:
Hydraulic
Max. Length To Shear:
1600mm
Voltage:
21.5Mpa, Customized
Color:
Customized
Automatic Grade:
Automatic
Technical Specifications
Model Max Cutting Force (KN) Blade Length (mm) Shear Height (mm) Production Rate (t/h) Power (KW)
WS-400 4000 1000 300/420 4-7 74
WS-500 5000 1400/1600 300/420 6-9 90
WS-630 6300 1400/1600 300/420 8-15 135
WS-800 8000 1600 420/500 12-18 180
WS-1000 10000 1600/2100 420/500 15-25 225
Commercial Terms
Minimum Order Quantity:
1 Set
Price:
Negotiable
Payment Terms:
30% T/T In Advance
Supply Ability:
5 sets /month
Delivery Time:
As your requirement
Packaging Details:
Seaworthy packing
After-sales Service:
Engineers are available to overseas service
