WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing

  • WS-1000G Gantry Heavy Duty Scrap Metal Shear with 1000 Ton Cutting Force and 2100mm Blade for Industrial Scrap Processing
Lugar de origem Jiangsu, China
Marca DLK
Certificação CE, ISO 9001
Número do modelo WS-1000G
Quantidade de ordem mínima 1 conjunto
Preço USD 185000-215000 per Set
Detalhes da embalagem Estrutura de aço com embalagem protetora, transporte de contêiner ou flat rack
Tempo de entrega 45-60 dias úteis
Termos de pagamento L/C, T/T
Habilidade da fonte 5 séries por mês
Detalhes do produto
Modelo WS-1000G Tipo de estrutura Quadro de pórtico
Força de corte máximo 1000 toneladas Comprimento da lâmina 2100 mm
Altura da tesoura 420/500 de milímetro Placa de aço máxima Espessura de 80mm
Aço redondo máximo Φ150 mm Potência total 275 quilowatts
Sistema de controle Tela de toque PLC + remoto Resfriamento Sistema de tubo de resfriamento de água
Destacar

Gantry Frame Metal Shear

,

2100mm Heavy Duty Cutter

,

1000 Ton Scrap Processor
Deixe um recado
Descrição de produto
WS-1000G Gantry Heavy Duty Scrap Metal Shear 2100mm Blade 1000 Ton Cutting Force Steel Plate Processing
WS-1000G Gantry Type Heavy Duty Scrap Metal Shear

The WS-1000G represents a departure from conventional container-type shears, featuring a robust gantry frame structure engineered for extreme-duty scrap processing. With 1000 tons of cutting force and a massive 2100mm blade, this machine handles oversized scrap that standard shears cannot process — including heavy structural steel, railway tracks, thick ship plates, and industrial machinery remnants.

Key Advantages of Gantry Design
  • Superior Structural Rigidity: Heavy steel gantry frame withstands extreme lateral forces without deformation
  • 2100mm Extended Blade: 30% longer than standard container models for processing oversized materials
  • 1000 Ton Cutting Force: Capable of shearing steel plates up to 80mm thick and round steel up to Φ150mm
  • Large Feed Opening: 3500mm x 2500mm hopper accommodates bulky scrap without pre-processing
  • Twin Shear Cylinder Design: YG500/320 cylinders with 5000kN x 2 force for balanced cutting
  • Industrial Grade Hydraulics: Heavy-duty Rexroth-type variable displacement pumps for continuous operation
Applications

Designed for heavy industrial applications including ship dismantling yards, large-scale steel mills, railway scrap processing, bridge demolition recycling, and heavy machinery disposal facilities.

Technical Specifications
Parameter Specification
Model WS-1000G
Structure Type Gantry Frame
Max Cutting Force 1000 Tons
Blade Length 2100 mm
Shear Height 420/500 mm
Cutting Speed 2-3 times/min (load)
Processing Capacity 15-25 tons/hour
Total Power 275 KW
Shear Cylinder YG500/320 x 2 (5000kN each)
Press Cylinder YG320/250 (2000kN)
Max Steel Plate Thickness 80 mm
Max Round Steel Diameter Φ150 mm
Feed Opening 3500 x 2500 mm
Hydraulic System Pressure ≤ 31.5 MPa
Control System PLC Touch Screen + Remote Control
Cooling System Water Cooling with Tube Cooler
Power Supply 380V/3P 50Hz (Customizable)
Machine Weight 68 Tons
Overall Dimensions 15000 x 3500 x 4200 mm
Our Service
  • 24/7 online technical support with remote diagnostics
  • One year comprehensive warranty with lifelong maintenance
  • Free spare parts for manufacturing defects within warranty
  • On-site installation, commissioning, and operator training available
  • Custom engineering solutions for specific scrap processing requirements

Contact our engineering team for a detailed proposal and site assessment.
